SunTouch ProMelt PM-5C Detector, 120/208/240V 60A
The SunTouch ProMelt PM-5C Detector 120/208/240V 60A is an all-in-one control that includes a snow sensor on the top facing side.
$756.61
Brand: SunTouch
Availability: Ships from Factory (More Info)
Shipping: Free to Continental US (More Info)
SKU
ST 81014247
The SunTouch ProMelt PM-5C Snow Detector operates on line voltage with a 60-Amp capacity. This all-in-one control includes a snow sensor on the top facing side. The integrated snow sensor is heated to allow for snow, ice, or freezing rain to melt, allowing proper detection of environmental conditions.
- Automatic or manual operation
- Adjustable trigger temperature
- Adjustable drying cycle
SunTouch ProMelt Sensor Control Specs:
| Model# | AMP Capacity | Device Type | Programming Capability | UL Listing | Order# | |
| PM-2C | 300600 | 30.00 | Sensor | Non Programmable | N-No UL Code Rating | 81011699 |
| PM-5C | 300580 | 60.00 | Sensor | Non Programmable | N-No UL Code Rating | 81014247 |
Select the best control package for your installation.
- Total the amps of the mat and cable for each zone before comparing control options.
- Zones with less than 60 amps can use an all-in-one control solution (PM-2C or PM-5).
- The PM-L1 to L3 & PM-519 kits connect to a ContactorPro panel to control zones of any size.
| System Size | Operation | Sensor | Control | Required | Recommended |
| Up to 30 amp | Automatic start/timed stop melting | Pole-Mount | PM-2C | - | PM-DP |
| Up to 60 amp | Automatic start/timed stop melting | Pole-Mount | PM-5 | - | PM-DP |
| Any Size | Automatic start & stop melting with slab temperature control |
Surface-Mount | ProMelt Smart Controller | ContactorPro Panel | - |
| Any Size | Automatic start/timed stop melting | Pole-Mount | ProMelt Smart Controller | ContactorPro Panel | - |
| Any Size | Manual start & stop melting with slab temperature control |
In-Slab | ProMelt Smart Controller | ContactorPro Panel | - |
| Any Size | Outdoor patio heating (no snow melting) | In-Slab | PM-519 | ContactorPro Panel | - |
*SunTouch now requires all orders shipping from the factory to ship with signature required.
| SKU | ST 81014247 |
|---|---|
| UPC | 840213149451 |
| Non-Returnable | No |
| Manufacturer | SunTouch |
| Warranty | 3 Year Limited Warranty |
| Manufacturer Part Number | 300580 |
| Order Number | 81014247 |
| Voltage | 120/208/240/277 |
| Weight (lbs.) | 3.00 |
| Dimensions (L x W x H) | 5" x 7" x 3" |
