Makita 5377MG 7‑1/4" Magnesium Hypoid Saw
Brand: Makita
Availability: Sold In Store - Ships From Store (1 available in store). (More Info)
Shipping: Standard (More Info)
Makita 5377MG 7‑1/4" Magnesium Hypoid Saw features highly durable magnesium components and a powerful 15 AMP Makita-built industrial motor with a hypoid gearing system for maximum power output. The 5377MG seamlessly balances weight, power, durability, and ease of use for optimum cutting performance.
The 5377MG features a Makita-built 15 AMP industrial motor that delivers 4,500 RPM, combined with well-balanced magnesium components for a lighter weight saw that delivers true power the professional user demands. Users will benefit from the precision-machined hypoid gears, which deliver more constant power than worm drive gears. Hypoid gears have greater surface contact so more power is transferred over a wider surface, providing increased power and durability. In addition, hypoid gears are in an oil bath for consistent oil coverage.
Additional design details include greater clearance between the rear handle and the blade case to provide a better grip for larger hands or for users with gloves, as well as a wider space between the blade and housing for a clearer view of the blade and measurement scale. Makita also engineered ergonomics and ease-of-use into the saw, including clearly visible depth and bevel markings and ergonomic hand grips to improve overall control while minimizing operator fatigue. The large rubberized levers provide quick, one-handed adjustments for more efficient work.
The 5377MG includes a Makita 7-1/4" Premium Ultra-Coated Framing Blade with Advance Tooth Design. The "M" shaped tooth design features a two-pointed tip and two 10 degrees bevel face to maximize cutting performance for a faster, cleaner, and longer-lasting cut. The carbide tips are specifically set to withstand the harshest conditions such as plowing through nail-embedded wood. The blade is also ultra-coated to reduce heat and pitch build-up for faster, smoother cutting, with special Makita heat vents strategically set to dissipate heat and increase performance. The 5377MG also includes a blade wrench attached to the saw for fast and convenient blade changing.
The 5377MG is built for framing walls, floors and roofs using a range of dimensional lumber and dense engineered lumber, including LVL, PSL and I-Joists, headers, and microlams; as well as ripping panels such as plywood, OSB, particleboard, and dense structural panels. Other applications include plunge and bevel cutting.
Makita 5377MG 7‑1/4" Magnesium Hypoid Saw Features:
- Magnesium components create a lightweight saw that is well balanced and job site tough
- Oil bath technology is created with a built-in fan and sealed gear housing to ensure 100% oil surface coating for less maintenance
- Large cutting capacity (2-3/8" at 90°) with positive stops at 22.5°, 45° and 51.5°
- High quality, heat treated hypoid steel gears are engineered for less maintenance
- Powerful 15 AMP motor delivers 4,500 RPM with compressed winding technology to keep the overall size more compact yet deliver job site durability
- Better fit with comfortable rubber grip on handle
- Retractable hook allows tool to remain close by, but never in the way
- Make quick, one-handed adjustments using large, rubberized levers
- Settings are easy to read with oversized number and ruler markings
- Blade wrench is attached to saw for fast and convenient blade changing
Makita Magnesium Hypoid Saw Specifications:
| Max. Cutting Capacity (at 90°) | 2-3/8" |
| Max. Cutting Capacity (at 45°) | 1-3/4" |
| Max. Cutting Capacity (at 50°) | 1-9/16" |
| Power Type | Corded |
| SKU | T-MA 5377MG |
|---|---|
| In the Box |
|
| UPC | 088381076944 |
| Manufacturer | Makita |
| Manufacturer Part Number | 5377MG |
| Amps | 15 |
| Arbor Size | 5/8" |
| Overall Length | 17-3/4" |
| Weight (lbs.) | 13.2 |
| No Load Speed (rpm) | 4,500 |
| Wheel Diameter | 7-1/4" |
| Dimensions (L x W x H) | 21.75" x 11.75" x 12.5" |
| Watts | 2,300 |
| Voltage | 120 |
