Alpha Quad Turbo Diamond Blade - 8" - 9" - 10"
Alpha Quad and the Quad Drive Adapter offer unique features with the performance of the ultimate diamond blade for special applications.
As low as $92.84
Brand: Alpha Tools
Availability: Sold In Store - Ships From Store (More Info)
Shipping: Free on orders over $99 to Continental US (More Info)
Only %1 left
SKU
T-ALPH DA
Alpha Quad and the Quad Drive Adapter offer unique features with the performance of the ultimate diamond blade for special applications.
Alpha Quad accepts exclusive Quad Drive Adapter, which eliminates the required lock nut. The Quad Drive Adapter has a threaded arbor that permits mounting on angle grinders for "flush cutting" applications. The quad driver designed for larger diameters enables angle grinders to be used for cutting applications with their existing safety guard in place.
Features:
- Requires Quad Drive to fit High-Speed Angle Grinder
- Fits most popular High-speed Angle Grinders
- Specially Designed for Flush Cutting
- Best Dry Cutting Turbo Blade on the Market
- Chip-Free Cutting on Most Demanding Applications
Alpha Quad Turbo Diamond Blade Specifications:
| Part No. | Size | Thickness | Maximum RPM | Arbor(s) |
| DA08AH | 8" | 2.3mm/.090" | 7,400 | 20mm Flange with 8 holes |
| DA09AH | 9" | 2.5mm/.098" | 6,600 | 20mm Flange with 8 holes |
| DA11AH | 10" | 2.5mm/.098" | 5,900 | 20mm Flange with 8 holes |
| SKU | T-ALPH DA |
|---|---|
| Non-Returnable | No |
| Manufacturer | Alpha Tools |
| Blade Type | Continuous Rim Turbo |
| Arbor Size | 20mm Flange with 8 holes |
| No Load Speed (rpm) | 7,400 - 5,900 |
| Ceramic Tile Performance | Excellent |
| Porcelain Tile Performance | Excellent |
| Glass Tile Performance | Good |
| Marble Performance | Excellent |
| Thickness | .090" - .098" |
| Wet or Dry | Wet or Dry |
| Dimensions (L x W x H) | 8" x 8" x .090" - 10" x 10" x .098" |
