Aardwolf Transport Frame
Brand: Aardwolf
Availability: Sold in Store - Ships from Store or Factory (More Info)
Shipping: Standard (More Info)
The Aardwolf Transport Frame is for transporting vanity tops and other workpieces. With a durable structure, together with locking bars and straps, this frame can hold the vanity tops and other workpieces securely. The Transport Frame is quick to assemble and disassemble, with assembly time by one man taking approximately 5 minutes. The loaded frame can be moved around a factory or work site manually by one man. The fully loaded frame can be loaded on and offloaded from trucks by forklift.
Aardwolf Transport Frame Features:
- Sturdy structure, designed to eliminate any risk of the slab tipping over
- Slabs are placed on special rubber profiles and secured with 6 locking bars together with ratchet straps to retain materials.
- The frame features 2 hooking points to be picked up by an overhead crane
- Reinforced with two oblique bars for the firm and secure construction
- Built-in forklift receivers on all sides for lifting by forklift
- The base and uprights come with replaceable white rubber to prevent marking and scratches.
- Counter-lever handle with wheels, allow the frame to be moved manually even when loaded.
- A Counter-lever handle is used to jack uploaded frame and lower support legs when wheels are not required.
- Powder-coated finish, which ensures an aesthetic feature as well as the durability of the product
Option:Â The frames can be hot galvanized finished upon request.
Note:Â Support legs should always be lowered when a loaded frame is being transported on a truck.
Aardwolf Transport Frame Specifications:
| Â | TF2000 | TF2440 | TF3050 | TF3050H | ||||
| Metric (mm-kg) | Imperial (inch-lbs) | Metric (mm-kg) | Imperial (inch-lbs) | Metric (mm-kg) | Imperial (inch-lbs) | Metric (mm-kg) | Imperial (inch-lbs) | |
| Number of wheels | 4 | - | 4 | - | 4 | - | 4 | - |
| Straps of each side | 3 | - | 4 | - | 5 | - | 3 | - |
| Width of slab storage base area on each side |
268 mm | 10.6" | 268 mm | 10.6" | 268 mm | 10.6" | 207 mm | 8" |
| Length | 2,000 mm | 78.7" | 2,440 mm | 96" | 3,050 mm | 120" | 3,050 mm | 120" |
| Height | - | - | - | - | - | - | 2,317 mm | 91.2" |
| Working load limit per side | 1,250 kg | 2,756 lbs | 1,250 kg | 2,756 lbs | 1,250 kg | 2,756 lbs | 1,250 kg | 2,756 lbs |
| Total working load limit | 2,500 kg | 5,511 lbs | 2,500 kg | 5,511 lbs | 2,500 kg | 5,511 lbs | 2,500 kg | 5,511 lbs |
| Net weight | 182 kg | 401 lbs | 206 kg | 454 lbs | 239 kg | 527 lbs | 260kg | 573 lbs |
| Gross weight | 188 kg | 414 lbs | 212 kg | 467 lbs | 245 kg | 540 lbs | 266 kg | 586 lbs |
| Packaging dimension | 2,000 x 1,020 x 420 mm | 78.7" x 40.2" x 16.5" | 2,450 x 1,020 x 420 mm | 96.5" x 40.2" x 16.5" | 3,050 x 1,120 x 430 mm | 120" x 44" x 16.9" | 3,050 x 1,030 x 450 mm | 120" x 40.5" x 17.7" |
| SKU | T-AW TF |
|---|---|
| Weight (lbs.) | 401.0 - 573 |
| Non-Returnable | No |
| Manufacturer | Aardwolf |
| Dimensions (L x W x H) | 78.74" x 40" x 66.88" - 120" x 40" x 91.2" |
